2.50mm Height 2420 Package Top View White Chip LED

LL-R6050xx-TR8 Series

Item: LL-R6050xx-TR8 Series

Product Description

Features:
◇ P-LCC package.
◇ Lead frame package with individual 6 pins.
◇ Available on tape and reel (12mm Tape).
◇ White SMT package.
◇ Super luminosity white LED.
◇ Built in 5 LED chips.
◇ The Chips can be controlled separately.
◇ Optical indicator.
◇ Colorless clear window.
◇ Ideal for backlight and light pipe application.
◇ Inter reflector.
◇ Low current (2mA) operation.
◇ High performance.
◇ Wide viewing angle.
◇ Suitable for automatic placement equipment.
◇ Suitable for vapor-phase reflow, infrared reflow and wave solder processes.
◇ The product itself will remain within RoHS complaint Version.
Descriptions:
◇ The R6050 is available in soft red, orange, yellow, green, blue and white. Due to the
Package design, the LED has wide viewing angle and optimized light coupling by inter
reflector, this feature makes the SMT TOP LED ideal for light pipe Application. The low
current requirement makes this device ideal for portable equipment or any other
application where power is at a premium.
Applications:
◇ Automotive: Backlight in dashboards and switches.
◇ Telecommunication: Indicator and backlight in telephone and fax.
◇ Indicator and backlight for audio and video equipment.
◇ Indicator and backlight in office and family equipment.
◇ Flat backlight for LCD’s, switches and symbols.
◇ Light pipe application.
◇ General use.
